Camera
Image Sensor 1/3″ progressive scan CMOS
Effective Pixels 1320K pixels
Minimum Illumination
White Balance
Color: 0.05 lux @ ƒ/1.6, B/W: 0.005 lux @ ƒ1/.6
Auto/manual/ATW/indoor/outdoor/daylight lamp/sodium lamp
AGC Auto/manual
S/N Ratio ≥50 dB
Digital Noise Reduction 3D DNR
Backlight Compensation HLC/BLC
Wide Dynamic Range Digital WDR
Shutter Speed 1 to 1/30,000 sec.
Day/Night IR cut filter
Digital Zoom 12x
Privacy Masking 24 privacy masks programmable, optional multiple colors and mosaics
Focus Mode Auto/semiautomatic/manual
Enhancement Defog
Lens
Focal Length 4.3 mm to 129 mm, 30x optical zoom
Zoom Speed Approximately 3 s (optical wide to tele)
Angle of View 57.4° to 2.8° (wide to tele)
Min. Working Distance 10 mm to 1500 mm (wide to tele)
Aperture Range ƒ/1.6 to ƒ/5.0
Pan and Tilt
Smart Tracking Supported
Pan/Tilt Range Pan: 360° endless; tilt: -5° to 90° (auto flip)
Pan/Tilt Speed
Proportional Zoom
Pan manual speed: 0.1° to 300°/s, pan preset speed: 540°/s
Tilt manual speed: 0.1° to 240°/s, tilt preset speed: 400°/s
Rotation speed can be adjusted automatically according to zoom multiples
Number of Presets 256
Patrols 8 patrols, up to 32 presets per patrol
Patterns 4 patterns, with the recording time not less than 10 minutes per pattern
Power-Off Memory Supported
Park Action Preset/patrol/pattern/pan scan/tilt scan/random scan/frame scan/panorama scan
PTZ Position Display Supported
Preset Freezing Supported
Scheduled Task Preset/patrol/pattern/pan scan/tilt scan/random scan/frame scan/panorama scan/dome reboot/selftest action/alarm output
Alarm
Alarm Input 7 inputs
Alarm Output
Alarm Trigger
2 relay outputs, alarm response actions configurable
Motion detection, audio exception detection, dynamic analysis, tampering alarm, network disconnect,
IP address conflict, storage exception
Alarm Actions Preset, patrol, pattern, SD/SDHC card recording, relay output, notification on client
Local Video and Audio
Video Output
Audio Input
Audio Output
1.0 V[p-p]/75 Ω, NTSC (or PAL) composite, BNC
1 mic in/line in interface. Line input: 2 to 2.4 V[p-p]; output impedance: 1K Ω, ±10%
1 audio output interface. Line level, impedance: 600 Ω
Network
Ethernet 10Base-T/100Base-TX, RJ-45 connector
Max. Image Resolution 1280 × 960
Frame Rate
Image Compression
30 fps (1280 × 960), 30 fps
(1280 × 720) H.264/MJPEG/MPEG4, H.264 encoding with Baseline/Main/High profile
SVC Supported
ROI Encoding Supported
Audio Compression G.711u/G.711a/G.726/MP2L2
Protocols IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP,
TCP, UDP, IGMP, ICMP, DHCP, PPPoE
Simultaneous Live Views Up to 10
Streams Triple streams
SD Memory Card
User/Host Levels
Security Measures
Built-in microSD/SDHC slot, up to 128 GB, supports manual/alarm/edge recording
Up to 32 users, 3 levels: administrator, operator, and user
User authentication (ID and PW), host authentication (MAC address), IP address filtering
Integration
Application Programming Open-ended API, supports ONVIF, PSIA, ISAPI, and CGI
Web Browser IE 7+, Chrome 18+, Firefox 5.0+, Safari 5.02+, supports multi-language
General
RS-485 Protocols HIKVISION, Pelco-P, Pelco-D, self-adaptive
Power -AEL: 24 VAC, maximum 60 W/High-PoE, maximum 40 W
-AE3: 24 VAC/PoE+, maximum 25 W
Working Temperature -AEL: 24 VAC: -40° C to 65° C (-40° F to 149° F)/High-PoE: -30° C to 65° C (-22° F to 149° F)
-AE3: -10° C to 50° C (14° F to 122° F)
Humidity 90% or less
Protection Level IP66, TVS 4,000 V lightning protection, surge protection, and voltage
transient protection IK 10 (optional)
Dimensions Φ220 mm × 325.5 mm (Φ8.66″ × 12.81″) (outdoor)
Φ183.4 mm × 243 mm (Φ7.22″ × 9.57″) (indoor)
Weight Approximately 5 kg (11.02 Ibs)
