• Image Sensor 1/2.7″ Progressive Scan CMOS
  Min. Illumination Color: 0.01 Lux @(F2.0, AGC ON), B/W: 0 Lux with IR
• Shutter Speed 1/3 s to 1/100, 000 s
• Slow Shutter Yes
• Wide Dynamic Range Digital WDR
• Day & Night IR cut filter
• Angle Adjustment Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°

Lens

• Focal Length & FOV
• 2.8 mm, horizontal FOV 112.1°, vertical FOV 60.0°, diagonal FOV 132.2°
• 4 mm, horizontal FOV 90.2°, vertical FOV 48.6°, diagonal FOV 107.6°
• Lens Mount M12
• Focus Fixed
• Aperture F2.0

Illuminator

• IR Wavelength 850 nm
• IR Range Up to 30 m
• Video
• Max. Resolution 1920 × 1080
• Main Stream
• 50 Hz: 25 fps (1920 × 1080, 1280 × 720)
• 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
• Sub-Stream
• 50 Hz: 25 fps (640 × 480, 640 × 360)
• 60 Hz: 30 fps (640 × 480, 640 × 360)
• Video Compression
• Main Stream: H.265/H.264
• Sub-Stream: H.265/H.264/MJPEG
• Video Bit Rate 32 Kbps to 8 Mbps
• H.264 Type Baseline Profile/Main Profile/High Profile
• H.265 Type Main Profile
• H.264+ Main Stream supports
• H.265+ Main Stream supports
• Region of Interest (ROI) 1 fixed region for main stream

Audio

• Audio Compression
• G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC
• Audio Bit Rate
• 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16
• Kbps (G.726)/32 to 160 Kbps
• (MP2L2)/16 to 64 Kbps (AAC)
• Audio Sampling Rate 8 kHz/16 kHz
• Environment Noise Filtering Yes

Network

• Protocols
  TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™,
  SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
• Simultaneous Live View Up to 6 channels
• API Open Network Video Interface, ISAPI
• User/Host Up to 32 users. 3 levels: administrator, operator and user
• Network Storage MicroSD/SDHC/SDXC card (256 GB) local storage
• Client iVMS-4200, Hik-Connect
• Web Browser
• Plug-in required live view: IE 10+
• Plug-in free live view: Chrome 57.0+, Firefox 52.0+
• Local service: Chrome 57.0+, Firefox 52.0+


• Image Settings
• Saturation, brightness, contrast, sharpness, AGC, white
• balance adjustable by client
• software or web browser.
• Day/Night Switch Day, Night, Auto, Schedule
• Image Enhancement BLC, 3D DNR

Interface

• Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
• On-Board Storage Built-in memory card slot, support
• microSD card, up to 256 GB
• Built-in Microphone Yes
• Hardware Reset Yes
• Event
• Basic Event Motion detection, video tampering alarm, exception

General

• Linkage Method
• Upload to FTP/memory card, notify surveillance center,
• send email, trigger recording,
  trigger capture
• Camera Material Metal & Plastic
• Camera Dimension Ø110 mm × 85.3 mm (Ø4.3″ × 3.4″)
• Package Dimension 150 mm × 150 mm × 141 mm (5.9″ × 5.9″ × 5.6″)
• Camera Weight Approx. 320 g (0.7 lb.)
• With Package Weight Approx. 556 g (1.2 lb.)
• Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F).
• Humidity: 95% or less (non-condensing)
• Startup and Operating
• Conditions
  -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
• Web Client Language English, Ukrainian
• General Function
• Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP
  address filter
• Firmware Version V5.5.120
• Power Consumption and Current
  12 VDC, 0.4 A, max. 5 W
• PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.15 A, max. 6.5 W
• Power Supply
  12 VDC ± 25%
• PoE: 802.3af, Class 3
• Power Interface Ø5.5 mm coaxial power plug

Approval

• EMC
• FCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014,
• EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC
• VoC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
• Safety
• UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 +
• Am 2:2013, IEC 62368-1:2014);
• CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013,
• IEC 62368-1:2014); BIS (IS
  13252(Part 1):2010+A1:2013+A2:2015)
• Environment CE-RoHS (2011/65/EU); WEEE (2012/19/EU);
• Reach (Regulation (EC) No 1907/2006)
• Protection IP67 (IEC 60529-2013)
