Camera 3K

• Image Sensor3K CMOS
• Max. Resolution2960 (H) × 1665 (V)
• Min. Illumination0.02 Lux @ (F2.2, AGC ON), 0 Lux with IR
• Shutter TimePAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
• Day & NightICR
• Angle AdjustmentPan: 0 to 360°, Tilt: 0 to 90°, Rotate: 0 to 360°
• Signal SystemPAL/NTSC

Lens

• Lens Type2.8 mm, 3.6 mm fixed focal lens
• Focal Length & FOV

  2.8 mm, horizontal FOV: 101°, vertical FOV: 64°, diagonal FOV: 125°

  3.6 mm, horizontal FOV: 80°, vertical FOV: 51°, diagonal FOV: 98°

• Lens MountM12

Illuminator

• Supplement Light Range

  IR : Up to 20 m

  White Light : Up to 20 m

• Supplement Light TypeSmart,IR,White Light


• Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
• Image SettingsBrightness, Sharpness, Smart IR
• Frame Rate

  TVI: 3K @20 fps, 4 MP @25 fps/30 fps, 1080p @25 fps/30 fps

  AHD: 5 MP @20 fps, 4 MP @25 fps/30 fps

  CVI: 4 MP @25 fps/30 fps

  CVBS: PAL/NTSC

• Day/Night ModeAuto/Color
• Wide Dynamic Range (WDR)Digital WDR
• Image EnhancementDWDR/BLC/HLC/HLS/Global
• White BalanceAuto/Manual
• AGCYes

Interface

• Video OutputSwitchable TVI/AHD/CVI/CVBS

General

• MaterialMetal
• DimensionØ70 mm × 138.8 mm (Ø2.76″ x 5.46″)
• Max. 265 g (0.58 lb.)
• Operating Condition-40 °C to 60 °C (-40 °F to 140 °F). Humidity: 90% or less (non-condensation)
• CommunicationHIKVISION-C
• LanguageEnglish
• Power Supply

  12 VDC ± 25%, Max. 5.0 W

  *You are recommended to use one power adapter to supply the power for one camera.

Approval

• ProtectionIP67
