Camera
Image Sensor8.29 megapixel progressive scan CMOS
Max. Resolution3840 (H) × 2160 (V)
Min. IlluminationColor: 0.003 Lux@(F1.2, AGC ON), 0 Lux with IR
Shutter TimePAL: 1/12.5 s to 1/10,000 s ,NTSC: 1/15 s to 1/10,000 s
Day & NightIR cut filter
Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360°
Signal SystemPAL/NTSC
Slow ShutterMax. 16 times
Lens
Lens Type2.8 mm, 3.6 mm, 6 mm fixed focal lens
Focal Length & FOV102.2° (2.8 mm), 79° (3.6 mm), 50.8° (6 mm)
Lens MountM12
Image SettingsContrast, Sharpness, Saturation, Mirror, Defog, HLC
Frame RatePAL: 8 MP@12.5fps, 5 MP@20fps, 4 MP@25fps, 1080p@25fps,NTSC: 8 MP@15fps, 5 MP@20fps, 4 MP@30fps, 1080p@30fps
Day/Night ModeAuto/Color/BW (Black and White)
Wide Dynamic Range (WDR)120 dB
Image EnhancementBLC
Privacy MaskON/OFF, 4 programmable privacy masks
Noise ReductionLevel 1 to 10
White BalanceAuto/Manual/Natural
AGCSupport
Interface
Interface
Video OutputTVI&CVBS
General
MaterialEnclosure: Plastic,Main Body: Metal,Mounting Base: Plastic
DimensionØ 109.8 mm × 96.3 mm (Ø 4.32″ × 3.79″ )
WeightApprox. 360 g (0.79 lb.)
Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
CommunicationUp the coax, Protocol: HIKVISION-C (TVI output)
LanguageEnglish
Power Supply12 VDC ±25%,*You are recommended to use one power adapter to supply the power for one camera.
ConsumptionMax. 4.8 W
IR RangeUp to 60 m
Approval
ProtectionIP67
