توضیحات
برای خرید دوربین 8 مگاپیکسل هایک ویژن مدل دیگر کلیک کنید: قیمت DS-2CD2T83G0-I8
مشخصات فنی دوربین مداربسته هایک ویژن
[expander_maker id=”1″ more=”مشاهده دیتاشیت محصول less=”بازگشت”]
| Camera |
| Image Sensor: |
|
1/2.5″ Progressive Scan CMOS |
| Signal System: |
|
PAL/NTSC |
| Min. Illumination: |
|
Color: 0.01 Lux @ (F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR |
| Shutter time: |
|
1/3 s to 1/100,000 s |
| Slow shutter: |
|
Support |
| Lens: |
|
2.8 mm, horizontal FOV: 102°, vertical FOV: 53°, diagonal FOV: 124°
4 mm, horizontal FOV: 79°, vertical FOV: 42°, diagonal FOV: 95°
6 mm, horizontal FOV: 50°, vertical FOV: 28°, diagonal FOV: 59°
8 mm, horizontal FOV: 40°, vertical FOV: 25°, diagonal FOV: 53° |
| Lens Mount: |
|
M12 |
| Adjustment Range: |
|
Pan: 0° to 360°, tilt: 0° to 100°, rotate: 0° to 360° |
| Day& Night: |
|
IR cut filter with auto switch |
| Wide Dynamic Range: |
|
120 dB |
| Digital noise reduction: |
|
3D DNR |
| Focus: |
|
Fixed |
| Compression Standard |
| Video Compression: |
|
H.265+/H.265/H.264+/H.264/MJPEG |
| Video bit rate: |
|
256Kbps~16Mbps |
| Triple Streams: |
|
Yes |
| Compression Standard |
| Video Compression: |
|
H.265+/H.265/H.264+/H.264/MJPEG |
| Video bit rate: |
|
256Kbps~16Mbps |
| Triple Streams: |
|
Yes |
| Image |
| Max. Image Resolution: |
|
3840 × 2160 |
| Frame Rate: |
|
50Hz: 12.5 fps (3840 × 2160), 20fps (3072 × 1728), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60Hz: 15 fps (3840 × 2160), 20fps (3072 × 1728), 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Sub Stream: |
|
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Third Stream: |
|
50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288)
60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240) |
| Image Enhancement: |
|
BLC/3D DNR/BLC |
| Image Settings: |
|
Saturation, Brightness, Contrast , Hue, Sharpness, AGC, White Balance |
| Target Cropping: |
|
No |
| ROI: |
|
1 fixed region for main stream and sub-stream |
| Day/Night Switch: |
|
Day/Night/Auto/Schedule |
| Network |
| Network Storage: |
|
microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Alarm Trigger: |
|
Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| Protocols: |
|
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP,
IGMP, 802.1X, QoS, IPv6, Bonjour |
| General Function: |
|
One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy
mask, Watermark, IP address filtering |
| System Compatibility: |
|
ONVIF (Profile S, Profile G),ISAPI |
| Interface |
| Communication Interface: |
|
1 RJ45 10M / 100M Ethernet interface |
| On-board storage: |
|
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Reset Button: |
|
Yes |
| Smart Feature-set |
| Behavior Analysis: |
|
Line crossing detection, intrusion detection |
| Line Crossing Detection: |
|
Cross a pre-defined virtual line |
| Intrusion Detection: |
|
Enter and loiter in a pre-defined virtual region |
| Recognition: |
|
Face Detection |
| General |
| Operating Conditions: |
|
-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing) |
| Power Supply: |
|
12 VDC ± 25%, PoE (802.3af Class3) |
| Power Consumption: |
|
I5:
12 VDC, 0.7 A, max. 7.5W
PoE: (802.3af, 36V to 57V), 0.3 A to 0.2 A, max. 9W
I8:
12 VDC, 0.9 A, max. 11W
PoE: (802.3af, 36V to 57V), 0.4 A to 0.2 A, max. 12.9W |
| Weather Proof: |
|
IP67 |
| IR Range: |
|
-I5: up to 50 m; -I8: up to 80 m |
| Dimensions: |
|
Camera: Φ 104.8 × 299.7 mm (Φ 4.1″ × 11.8″)
Package: 386 × 156 × 155 mm (15.2″ × 6.1″ × 6.1″) |
| Weight: |
|
Camera: 1200 g (2.7 lb.) |
[/expander_maker]
