توضیحات
مشخصات فنی دوربین مداربسته هایک ویژن
Camera:
Image Sensor 1/2.8″ progressive scan CMOS
Min. Illumination
Color: 0.05 Lux @(F1.8, AGC ON)
B/W: 0.01Lux @(F1.8, AGC ON)
0 Lux with IR
White Balance Auto/Manual/ATW (Auto Tracking White Balance)/Indoor/Outdoor/Fluorescent
Lamp/Sodium Lamp
AGC Auto/Manual
Shutter Time 1/1 s to 1/30,000 s
Day & Night IR Cut Filter
Digital Zoom 16×
Privacy Mask 24 programmable polygon privacy masks
Focus Mode Auto/Semi-automatic/Manual
Image Stabilization Optical Image Stabilization
WDR 120dB
Lens:
Focal Length 6.6 mm to 330 mm, 50× Optical
Zoom Speed Approx. 4.5 s (optical lens, wide-tele)
FOV
Horizontal field of view: 41.3° to 1.1° (wide-tele)
Vertical field of view: 23.6° to 0.6° (wide-tele)
Diagonal field of view: 47.4° to 1.3° (wide-tele)
Working Distance 10 mm to 1500 mm (wide-tele)
Aperture Range F1.8 to F5.5
IR
IR Distance Up to 500 m
PTZ
Movement Range (Pan) 360° endless
Pan Speed Configurable, from 0.1°/s to 160°/s, Preset Speed: 240°/s
Movement Range (Tilt) From -20° to 90°
Tilt Speed Configurable, from 0.1°/s to 120°/s, Preset Speed: 200°/s
Proportional Zoom Support
Presets 300
Patrol Scan 8 patrols, up to 32 presets for each patrol
Pattern Scan 4 pattern scans, record time over 10 minutes for each scan
Power-off Memory Support
Park Action Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama
Scan
PTZ Position Display ON/OFF
Preset Freezing Support
Scheduled Task Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama
Scan/Dome Reboot/Dome Adjust/Aux Output
Compression Standard
Video Compression:
Main Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264/MJPEG
Third Stream: H.265/H.264/MJPEG
H.264 Type Baseline Profile/Main Profile/High Profile
H.264+ Support
H.265 Type Main Profile
H.265+ Support
Video Bitrate 32 kbps to 16384 kbps
Audio compression G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
Audio Bitrate 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2)
Smart Feature
Perimeter Protection
Intrusion, Line Crossing, Region Entrance, Region Exiting
Support alarm triggering by specified target types (human and vehicle)
Filtering out mistaken alarm caused by target types such as leaf, light, animal, and flag, etc.
Event Detection Face Detection, Audio Exception Detection
Smart Tracking Manual Tracking, Auto Tracking (support tracking specified target types such as human and
vehicle), Event Tracking
Smart Record ANR (Automatic Network Replenishment), Dual-VCA
ROI Support
Image:
Max. Resolution 1920 × 1080
Main Stream
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
50fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
60fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream 50Hz: 25fps (704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)
Third Stream 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Image Enhancement HLC/BLC/3D DNR/Defog/ Optical Image Stabilization /Regional Exposure/Regional
Focus/Optical Defog
SVC Support
Network:
Network Storage Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/
CIPS), ANR
Alarm Linkage
Alarm actions, such as Preset, Patrol Scan, Pattern Scan, Memory Card Video Record,
Trigger Recording, Notify Surveillance Center, Upload to FTP/Memory Card/NAS, Send
Email, etc.
Protocols IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP,
RTCP, RTP, TCP/IP, DHCP, PPPoE, Bonjour
API Open-ended, support ONVIF, PSIA and CGI, support HIKVISION SDK and Third-Party
Management Platform
Simultaneous Live View Up to 20 channels
User/Host Up to 32 users.
3 levels: Administrator, Operator and User
Security Measures User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption;
IEEE 802.1x port-based network access control; IP address filtering
Client iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect
Web Browser IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51
Interface
Alarm Interface 7-ch alarm input/2-ch alarm output
Audio Interface 1-ch audio input (applicable microphone, plug-in power type), 2 to 2.4 V[p-p], 1 KΩ ± 10%
1-ch audio output, line level, impedance: 600 Ω
Network Interface 1 RJ45 10 M/100 M Ethernet Interface, Hi-PoE
RS-485 Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive
BNC 1.0 V [p-p]/75 Ω, NTSC (or PAL) composite, BNC
General:
Power 24 VAC (Max. 60 W) , Hi-PoE (Max. 50 W)
Working Environment Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity: ≤ 90%
Protection Level IP67 Standard, IK10 (only supported by camera without wiper), TVS 6000V Lightning
Protection, Surge Protection and Voltage Transient Protection
Material Aluminum alloy
Dimensions Φ 266.6 mm × 410 mm (Φ 10.50″ × 16.14″)
Weight Approx. 8 kg (17.64 lb)
