قیمت دوربین هایک ویژن مـدل DS-2CD2T45FWD-I8

ادامه توضیحات

Camera 4MP

Image Sensor1/2.5″ Progressive Scan CMOS

Min. IlluminationColor: 0.008 lux @(F1.2, AGC ON), 0.014 lux @(F1.6, AGC ON), 0 lux with IR

Shutter Speed1/3 s to 1/100,000 s

Slow ShutterYes

Wide Dynamic Range120dB

Day & NightIR Cut Filter

Angle AdjustmentPan: 0° to 360°, tilt: 0° to 100°, rotate: 0° to 360°

Lens

• FocusFixed
• Lens Type2.8, 4, 6, 8, 12 mm
• FOV2.8 mm, horizontal FOV: 109°, vertical FOV: 60°, diagonal FOV: 131°,4 mm, horizontal FOV: 88°, vertical FOV: 46°, diagonal FOV: 105°,6 mm, horizontal FOV: 53°, vertical FOV: 30°, diagonal FOV: 61°,8 mm, horizontal FOV: 41°, vertical FOV: 23°, diagonal FOV: 48°,12 mm, horizontal FOV: 25°, vertical FOV: 14°, diagonal FOV: 29°
• ApertureF1.6
• Lens MountM12
• Aperture TypeFixed

Illuminator

• IR RangeI5: Up to 50 m,I8: Up to 80 m
• Wavelength850nm

Video

Video

• Max. Resolution2688 × 1520
• Main Stream

  50Hz: 25 fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 × 720)

  60Hz: 30 fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 × 720)

• Sub Stream50Hz: 25 fps (640 × 480, 640 × 360, 320 × 240),60Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)
• Third Stream50Hz: 25 fps (1280 × 720, 640 × 360, 352 × 288),60Hz: 30 fps (1280 × 720, 640 × 360, 352 × 240)
• Video CompressionMain stream: H.265/H.264,Sub-stream: H.265/H.264/MJPEG,Third stream: H.265/H.264
• Video Bit Rate32 Kbps to 16 Mbps
• H.264 TypeMain Profile/High Profile
• H.265 TypeMain Profile
• H.264+Main stream supports
• H.265+Main stream supports
• Scalable Video Coding (SVC)H.264 and H.265 encoding support
• Region of Interest (ROI)Support 1 fixed region for main stream and sub-stream

Network

• Simultaneous Live ViewUp to 6 channels
• APIONVIF (PROFILE S, PROFILE G), ISAPI
• ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour, WebSocket, WebSockets
• User/HostUp to 32 users,3 levels: Administrator, Operator and User
• Network StorageSupport microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
• ClientiVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
• Web BrowserPlug-in required live view:,IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11,Plug-in free live view:,Chrome 45.0+, Firefox 52.0+
• Alarm TriggerMotion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error


• Day/Night SwitchDay/Night/Auto/Schedule
• Target CroppingNo
• DNR3D DNR
• Image EnhancementBLC/3D DNR/HLC
• Image SettingsRotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser

Interface

• On-board StorageBuilt-in microSD/SDHC/SDXC slot, up to 128 GB
• Hardware ResetYes
• Communication Interface1 RJ45 10M/100M self-adaptive Ethernet port

Event

Event

• Smart EventLine crossing detection, intrusion detection, object removal detection, unattended baggage detection
• Face DetectionYes
• Exception DetectionScene change detection

General

• Firmware VersionV5.5.80
• General FunctionOne-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
• Startup and Operating Conditions-30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing)
• Power Supply12 VDC ± 25%, Φ 5.5 mm coaxial plug power,PoE(802.3af, class 3)
• Power Consumption and CurrentI5:,12 VDC, 0.7 A, max. 7.5 W,PoE (802.3af, 36V to 57V), 0.3 A to 0.1 A, max. 9.5 W,I8:,12 VDC, 1 A, max: 11.5 W,PoE (802.3af, 36V to 57V), 0.4 A to 0.2 A, max. 12.9 W
• Camera DimensionCamera: Φ104.8 mm × 299.7 mm (Φ4.1″ × 11.8″),Package: 386 mm × 156 mm × 155 mm (15.2″ × 6.1″ × 6.1″)
• Camera WeightCamera: 1200 g (2.7 lb.)

Approval

• ProtectionIP67
